NE556N

NE556N Overview

This product is manufactured by Texas Instruments. This device belongs to the Standard type. This product has a 2 Timer, allowing for precise timing control. Supply Voltage - Max: 16 V Supply Voltage - Min: 4.5 V The minimum operating temperature of this product is 0 C. The product can operate at a maximum temperature of + 70 C. The product can operate at a maximum temperature of SMD/SMT. PDIP-14 package/case type is utilized by this product. Tube packaging for easy dispensing The height of the product is 4.57 mm. 19.3 mm long Texas Instruments is a trusted brand for quality electronics This product has a 200 mA, ensuring reliable performance in demanding applications. Low Level Output Current is - 200 mA Timers & Support Products product type 25 of 100 Clock & Timer ICs as subcategory 1. 0.032734 oz of Unit Weight

NE556N Image

NE556N Specifications

• Manufacturer: Texas Instruments
• Product Category: Timers & Support Products
• RoHS: Y
• Series: NE556
• Type: Standard
• Number of Internal Timers: 2 Timer
• Supply Voltage - Max: 16 V
• Supply Voltage - Min: 4.5 V
• Minimum Operating Temperature: 0 C
• Maximum Operating Temperature: + 70 C
• Mounting Style: SMD/SMT
• Package / Case: PDIP-14
• Packaging: Tube
• Height: 4.57 mm
• Length: 19.3 mm
• Width: 6.35 mm
• Brand: Texas Instruments
• High Level Output Current: 200 mA
• Low Level Output Current: - 200 mA
• Operating Supply Current: 4000 uA
• Product Type: Timers & Support Products
• Factory Pack Quantity: 25
• Subcategory: Clock & Timer ICs
• Unit Weight: 0.032734 oz
