| Mfr. #: | SN74LS05D |
|---|---|
| 制造商: | Texas Instruments |
| 描述: | Buffers & Line Drivers Hex w/ OC Output |
| 生命周期: | 制造商新产品。 |
| 数据表: | SN74LS05D 数据表 |
Product belongs to the 74LS series. Tube Alternate Packaging is the packaging method for this product Weight of 0.004564 oz SMD/SMT Mounting-Style SOIC-14 Operational temperature range: 0°C ~ 70°C Surface Mount mounting type Output-Type: Open Collector Number of channels: 5 Voltage Supply Range: 4.75 V ~ 5.25 V Supplier device package: 14-SOIC 6 is 8. - maximum quiescent current. Inverter logic type 0.8V is a Logic-Level-Low; 2V is the Logic-Level-High Maximum operating temperature of + 70 C Minimum operating temperature: 0 C Polarity: Inverting 33 uA is 92 nA. Maximum supply voltage of 5.25 V Minimum supply voltage is 4.75 V LS logic type 32 ns at 5 V is 23 microseconds. High-Level-Output-Current of - 0.1 mA 8 mA low-level output current Number-of-Input-Lines: 6 Input Number-of-Output-Lines: 6 Output
