| Mfr. #: | STD2805T4 |
|---|---|
| 制造商: | STMicroelectronics |
| 描述: | Bipolar Transistors - BJT LV fast-switching PNP power trans |
| 生命周期: | 制造商新产品。 |
| 数据表: | STD2805T4 数据表 |
Product belongs to the STD2805 series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.009185 oz SMD/SMT Mounting-Style TO-252-3, DPak (2 Leads + Tab), SC-63 Surface Mount mounting type Supplier device package: D-Pak Configuration Single Transistor type: PNP Maximum current collector Ic is 5A . Maximum collector-emitter breakdown voltage of 60V DC current gain minimum (hFE) of Ic/Vce at 200 @ 100mA, 2V. Product Attribute: Vce-Saturation-Max-Ib-Ic: 600mV @ 200mA, 5A Power-off control: 15000 mW Maximum operating temperature of + 150 C Minimum operating temperature: - 65 C Rated VCEO up to 60 V The transistor polarity is PNP. The 60 V voltage rating is 40 V. 6 V rating of 5 V Max DC collector current: 5 A Gain-Bandwidth-Product: 150 MHz Minimum hfe for DC collector-base gain is 200.
