STMUX7000QTR

STMUX7000QTR Overview

Product belongs to the STMUX7000Q series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.006653 oz SMD/SMT Mounting-Style QFN-32 Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Product function is Video Multiplexer/Demultiplexer. Supplier device package: 32-QFN (3x6) - is 8. Voltage supply source: Analog and digital Single Supply Circuit type: 7-Channel, VGA 6.5 Ohm maximum on-state resistance Voltage supply range: 3 V ~ 3.6 V This product has a 150μA of 200μA. The - 1 GHz bandwidth Power-off control: 500 mW Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Maximum supply voltage of 3.6 V Minimum supply voltage is 3 V 0.25 ns is 23 microseconds. Max on-resistance of 6.5 Ohms The - 32 dB of this product is 35 dB.

STMUX7000QTR Image

STMUX7000QTR Specifications

• Manufacturer STMicroelectronics
• Product Category Interface - Analog Switches, Multiplexers, Demultiplexers
• Series STMUX7000Q
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.006653 oz
• Mounting-Style SMD/SMT
• Package-Case QFN-32
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Function Video Multiplexer/Demultiplexer
• Supplier-Device-Package 32-QFN (3x6)
• Number-of-Circuits -
• Voltage-Supply-Source Single Supply
• Switch-Circuit -
• Circuit 7-Channel, VGA
• Multiplexer-Demultiplexer-Circuit -
• On-State-Resistance-Max 6.5 Ohm
• Channel-to-Channel-Matching-ΔRon -
• Voltage-Supply-Single-Dual 3 V ~ 3.6 V
• Current-Supply 150μA
• Voltage-Supply-Single-V+ -
• Voltage-Supply-Dual-V -
• Switch-Time-Ton-Toff-Max -
• -3db-Bandwidth -
• Charge-Injection -
• Channel-Capacitance-CS-off-CD-off -
• Current-Leakage-IS-off-Max -
• Crosstalk -
• Bandwidth 1 GHz
• Pd-Power-Dissipation 500 mW
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Supply-Voltage-Max 3.6 V
• Supply-Voltage-Min 3 V
• Propagation-Delay-Time 0.25 ns
• On-Resistance-Max 6.5 Ohms
• Off-Isolation-Typ - 32 dB
