Z0103MUF

Z0103MUF Overview

Product belongs to the Z01 series. Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style 3-SMB, Flat Lead Surface Mount mounting type Supplier device package: SMBflat-3L Configuration Single 7mA of Current-Hold-Ih-Max The Voltage-Off-State is 600V. Voltage-Gate-Trigger-Vgt-Max 1.3V 3mA of Current-Gate-Trigger-Igt-Max 1A is the maximum Current-On-State-It-RMS. This product can handle a non-repetitive surge current of 8A, 8.5A for 50-60Hz Itsm. Logic - Sensitive Gate Triac-Type Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Breakover Voltage 600 V 7 mA Maximun Holding Current of Ih The Gate-Trigger-Voltage-Vgt attribute is 1.3 V on this product. Gate-Trigger-Current-Igt: 5 mA; The 0.005 mA Off-State Leakage Current in VDRM and IDRM.

Z0103MUF Image

Z0103MUF Specifications

• Manufacturer STMicroelectronics
• Product Category Triacs
• Series Z01
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case 3-SMB, Flat Lead
• Mounting-Type Surface Mount
• Supplier-Device-Package SMBflat-3L
• Configuration Single
• Current-Hold-Ih-Max 7mA
• Voltage-Off-State 600V
• Voltage-Gate-Trigger-Vgt-Max 1.3V
• Current-Gate-Trigger-Igt-Max 3mA
• Current-On-State-It-RMS-Max 1A
• Current-Non-Rep#-Surge-50-60Hz-Itsm 8A, 8.5A
• Triac-Type Logic - Sensitive Gate
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Breakover-Voltage-VBO 600 V
• Holding-Current-Ih-Max 7 mA
• Gate-Trigger-Voltage-Vgt 1.3 V
• Gate-Trigger-Current-Igt 5 mA
• Off-State-Leakage-Current-VDRM-IDRM 0.005 mA
